DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet

DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
DUDE 4U 600x450 Wall-Mounted Rackmount Cabinet
  • Model: WS3-6404

Wall Mount, 19inch SPCC quality cold rolled steel, single section; Loading capacity: 100kg; Front door is tempered glass door with small round lock; 4PCS L-shaped mounting profiles; 2PCS removable side panel s with small round locks; Without fan or tray, two fan holes; Back panel with four mounting holes; package of:(15 cages, 15 nuts);

Quick Overview:

- Steel frame with assistant profile unassembled structure;

- Single section,compatible with 19" standard equipments;

- 5mm tempered glass front door with over 180 turning degree;

- Removable side panel,easy to install and lock optional;

- Cable entry on the top and bottom;

- L-shaped mounting profile,easy to adjustable on the mounting rail;

- Fan cutout on the top,easy to install fan;

- Back panel with four mounting holes,easy to fix on the wall;

- Various accessories for option;

- Flat packing,save the container space,easy to transport;


StandardComply with ANS/EIA RS-310-D,IEC297-2,DIN41491,PART1,DIN41491,PART7,ETSI Standard;
Material

SPCC quality cold rolled steelThickness: 1.2mmTempered glass Thickness:5mm

Loading CapacityStatic loading: 100kg
Degree of protectionIP20
Surface finishDegreasing,Pickling,Phosphating,Powder Coated
Product specification4U-18U
Width600mm
Depth

450mm,600mm

ColorRal9004; Ral9005; Ral7035



Specifications
Degree of protection IP20
Depth 450 mm, 600 mm
Loading Capacity Static loading: 100kg
Material: SPCC quality cold rolled steelThickness: 1.2mmTempered glass Thickness:5mm
Size 4U-18U
Standards: Comply with ANS/EIA RS-310-D,IEC297-2,DIN41491,PART1,DIN41491,PART7,ETSI Standard;
Width 600 mm
