Enterprise Campus 48 PoE (ECS-48-PoE (2150W))

The Ubiquiti Enterprise Campus 48 PoE (ECS-48-PoE) is a high-performance, enterprise-grade Layer 3 switch engineered for demanding network environments requiring high-density, multi-gigabit connectivity and robust power delivery.

Key Professional Features:

• High-Speed, High-Density Ports: Features a total of 48 PoE+++ (802.3bt, up to 90W per port) RJ45 ports, segmented into 16 $\times$ 2.5 GbE and 32 $\times$ 10 GbE ports, providing exceptional bandwidth for a high concentration of next-generation devices like Wi-Fi 7 access points, high-resolution cameras, and advanced workstations.

• High-Capacity Uplinks: Includes four 25G SFP28 fiber ports, ensuring massive uplink capacity for aggregating traffic and connecting to core network infrastructure or high-speed storage.

• Layer 3 Switching Capabilities: Provides a full Layer 3 feature set, including Inter-VLAN Routing, Static Routing, and DHCP Server/Relay, enabling efficient traffic management and segmentation without relying solely on a core router.

• High Availability & Redundancy: Designed for continuous operation with two hot-swappable 1,200W AC/DC power modules configured for power-sharing (up to 2,150W total PoE budget) or 1+1 redundancy. It also features four hot-swappable fan modules with $3+1$ redundancy for reliable thermal management.

• Exceptional Performance: Delivers a 920 Gbps Switching Capacity and 460 Gbps Non-Blocking Throughput, ensuring wire-speed performance across all ports to prevent bottlenecks in critical applications.

• Advanced Management & Visibility: Managed seamlessly via the UniFi Network application, offering a centralized interface for configuration, monitoring, and detailed network insights. The switch also features a 1.3" LCM touchscreen and Etherlighting™ on the ports for quick status identification.

• Comprehensive Layer 2 and Security: Supports a wide range of Layer 2 features (LACP, STP/RSTP, QoS, IGMP Snooping) and robust security protocols, including 802.1X control, MAC-Based Access Control Lists (ACLs), and DHCP Snooping/Guarding, to secure and optimize the network edge.




  Port Layout

  2.5 GbE RJ45

  16 (All PoE+++) (2.5G/1G/100M/10M)

  10 GbE RJ45

  32 (All PoE+++) (10G/5G/2.5G/1G/100M/10M)

  25G SFP28

  4 (25G/10G/1G)

  Max. PoE Output

  Up to PoE+++

  Total PoE Availability

  200-240V AC Shared Mode: 2,150W 100-120V AC Shared Mode: 1,750W 200-240V AC Redundant Mode: 950W 100-120V AC Redundant Mode: 750W

  Redundancy

  (2) Hot-Swappable PSUs (4) Hot-Swappable Fans

  Layer 3

  ✓

  Form Factor

  Rack mount (1U, Full-Depth)

  Etherlighting™

  ✓
  Performance

  Switching Capacity

  920 Gbps

  Total Non-Blocking Throughput

  460 Gbps

  Forwarding Rate

  684 Mpps

  Supported VLANs

  1,000

  MAC Address Table Size

  128,000

  L3 Table Size

  ARP Entries

  128,000

  IPv4 Routes

  256,000

  Packet Buffer Size

  8 MB

  Access Lists

  IPv4

  256

  MAC

  256
  Layer 3 Features

  DHCP Server (Local Networks)

  ✓

  DHCP Relay

  ✓

  Inter-VLAN Routing (Local Networks)

  ✓

  Static Routing (Local Networks)

  ✓
  Layer 2 Features

  LACP Port Aggregation

  ✓

  STP & RSTP

  ✓

  QoS (DSCP)

  ✓

  Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)

  ✓

  Advanced IGMP Configuration (Querier, Fast Leave, Router Port)

  ✓

  IGMP Snooping

  ✓

  802.1X Control

  ✓

  MAC-Based ACLs & Device Isolation

  ✓

  DHCP Snooping & Guarding

  ✓

  Egress Rate Limit

  ✓

  Flow Control

  ✓

  Storm Control

  ✓

  Multicast & Broadcast Rate Limiting

  ✓

  MAC Address Blocking

  ✓

  IP-Based ACLs & Network Isolation

  ✓

  MAC-Based Port Restriction

  ✓

  Port Isolation

  ✓

  Port Mirroring

  ✓

  Jumbo Frames

  ✓

  LLDP-MED

  ✓

  Voice VLAN

  ✓

  Loop Protection

  ✓
  Hardware

  PoE Ports
