Ubiquiti UniFi U7 Pro XGS (U7-Pro-XGS)

Ubiquiti UniFi U7 Pro XGS – Next-Gen WiFi 7 Access Point for High-Density Environments

The Ubiquiti UniFi U7 Pro XGS harnesses the power of Wi-Fi 7 (802.11be) to deliver ultra-fast, reliable wireless performance across a wide range of environments. Designed for demanding, high-density deployments, it operates across three frequency bands—2.4 GHz, 5 GHz, and 6 GHz—featuring 2x2 MU-MIMO on 2.4 and 6 GHz, and an enhanced 4x4 MU-MIMO on the 5 GHz band. This tri-band architecture supports peak speeds of 688 Mbps (2.4 GHz), 8.6 Gbps (5 GHz), and 5.8 Gbps (6 GHz), making it ideal for data-intensive applications.

Supporting up to 320 MHz channel bandwidth, the U7 Pro XGS maximizes spectrum efficiency while minimizing latency. With coverage up to 160 m² and support for 500+ concurrent clients, it's a robust solution for enterprise campuses, offices, hospitality venues, and public spaces.

Efficient Power and Intelligent Network Management

The U7 Pro XGS is built for modern networking needs with a 10 GbE RJ45 port, ensuring seamless wired integration with high-speed infrastructure. PoE++ support allows for single-cable installation, supplying both data and power (up to 29W) for simplified deployment.

Integrated with the UniFi Network platform, it offers centralized configuration, monitoring, and maintenance. Advanced networking features include:

Wireless meshing

Band steering

Fast roaming (802.11r)

Guest network isolation

Up to 8 BSSIDs per radio

Advanced QoS for traffic prioritization

These features help streamline network management and enhance user experience across a wide variety of applications.

Built to Perform in Any Environment

Crafted with both performance and durability in mind, the U7 Pro XGS features a compact and resilient design measuring 215 mm in diameter and 32.5 mm thick, with a total weight of 800 g. Its UV-stabilized polycarbonate and aluminum housing ensures long-term reliability in diverse settings.

High-gain internal antennas provide 4 dBi (2.4 GHz) and 6 dBi (5/6 GHz), while maximum transmit powers of 23 dBm (2.4 GHz), 29 dBm (5 GHz), and 24 dBm (6 GHz) ensure wide and stable coverage. It’s engineered to operate in conditions ranging from -30°C to 40°C, with humidity tolerance of 5% to 95% (non-condensing)—perfect for a variety of indoor environments.
