Ubiquiti UniFi U7 Pro XG (U7-Pro-XG)

Ubiquiti UniFi U7 Pro XG – Tri-Band WiFi 7 for High-Density Environments

The Ubiquiti UniFi U7 Pro XG is a high-performance access point powered by Wi-Fi 7 (802.11be), built to deliver exceptional speed, capacity, and efficiency in the most demanding network environments. Operating across the 2.4 GHz, 5 GHz, and 6 GHz bands with 2x2 MU-MIMO (uplink/downlink), it provides combined speeds of up to 10.8 Gbps—including 688 Mbps on 2.4 GHz, 4.3 Gbps on 5 GHz, and 5.8 Gbps on 6 GHz.

With support for up to 320 MHz channel widths, the U7 Pro XG ensures ultra-high throughput and low-latency communication. Designed to cover up to 140 m² and support 300+ concurrent clients, it’s ideal for high-density environments like campuses, enterprise buildings, hotels, and public venues.

Engineered for Durability & Performance

Housed in a UV-stabilized polycarbonate and aluminum alloy body, the U7 Pro XG combines sleek design with rugged durability. Compact at 206 mm x 32.5 mm and weighing 750 g, it integrates seamlessly into any indoor space.

Its internal high-gain antennas deliver strong, stable signals with gains of 4 dBi (2.4 GHz), 5 dBi (5 GHz), and 6 dBi (6 GHz). Maximum transmit powers reach 23 dBm, 26 dBm, and 24 dBm respectively, ensuring strong coverage throughout its range.

Built for diverse climates, it performs reliably in temperatures from -30°C to 40°C and humidity from 5% to 95% (non-condensing).

Streamlined Connectivity & Centralized Management

Equipped with a 10 Gigabit Ethernet port, the U7 Pro XG provides fast and reliable wired backhaul. Power over Ethernet (PoE+) support (up to 22W) reduces cabling complexity, making installation straightforward and clean.

Seamlessly integrated with the UniFi Network platform, this access point offers centralized monitoring, configuration, and optimization. Key features include:

Advanced QoS & traffic shaping

Wireless meshing

802.11r fast roaming

Band steering

Guest traffic isolation

Up to 8 BSSIDs per radio

These features ensure smooth client transitions, granular traffic control, and enhanced security—perfect for mission-critical wireless deployments.
