Ubiquiti uFiber OLT 4-port GPON optical line terminal with 4 GPON OLT SFP and 1 10 Gb / s SFP +, supporting 2.4 Gb / s downstream and up to 1.2 Gb / s upstream up to 20 km . Features: 4 GPON ports. Supports up to 512 clients (128 on the PON port). Up to 2.4 Gbit / s for transmission and up to 1.2 Gbit / s for reception. Supports GPON connections up to 20 km. One 1G / 10G SFP + Ethernet port. Convenient control properties level 2/3. FastEthernet management port, Serial console management port, Centralized management. Easily configure OLTs and manage multiple networks with UNMS ™ (Ubiquiti® Network Management System) software.
Specifications
Memory:
512 MB DDR3, 512 MB NAND
Operating Temperature:
-10 to 45 ° C (14 to 113 ° F)
Operating Humidity:
5 to 95% Noncondensing
Operation mode:
OLT 2/3 Ethernet Switch and GPON Core
Default IP:
192.168.1.1
Default name:
ubnt
Default password:
ubnt
Device dimensions:
299.80 x 258.95 x 42.55 mm (11.80 x 10.19 x 1.68")
Interface:
(4) GPON Ports, (1) 1G/10G SFP+ Ports, (1) RJ45 Ethernet Port, (1) RJ45 Serial Port
