UniFi® Access Reader Lite is a modern NFC and Bluetooth reader, a part of the UniFi Access solution.

The UniFi Access Reader Lite has been designed for convenient use and secure access. The PoE powered reader is easy to install and supports the latest NFC security standards including AES-128 encrypted MIFARE DESFire. Unlocking the door is quick and secure with NFC card or with mobile app.

Features:

• - Elegantly designed NFC and Bluetooth reader

• - 802.3af PoE powered by UniFi Access Hub

• - Advanced NFC credentials, including MIFARE DESFire

• - Built-in security element chip

• - For the best NFC security, use with our UA-Card

• - Mobile access with app (future software release)


UA-Lite will be shipped in silver color.

Note: UniFi Dream Machine Pro is required to run UniFi Access.

Package Contents

UA-Lite

Wall Mount

T6 Torx Screwdriver

Screw Kit

Security Screw

Installation Requirements Phillips screwdriver Ethernet cable, CAT5e or better Sample Wiring Topology  Door Position Switch  Externally Powered Door Opener  Magnetic Lock Hardware Overview LED Flashing White Initializing Steady Blue Adopted / device is ready Steady White Pending adoption Flash Blue Twice NFC card detected Flash White Twice Access denied Alternating White/Blue Upgrading firmware Hardware Installation Note: Determine the installation locations for each UA-Hub and door access reader. Cable runs for Ethernet should not exceed 100 meters; wire runs for lock cables should not exceed 45 meters. Peripherals Sample UniFi Access Diagram UA-Lite
