Ubiquiti USW Pro HD 24 PoE (USW-Pro-HD-24-PoE)

UniFi Switch Pro HD 24 PoE (USW-Pro-HD-24-PoE): High-Density Multi-Gigabit Backbone

The UniFi Switch Pro HD 24 PoE is a professional, Layer 3 managed switch built for environments demanding high-speed connectivity and maximum Power over Ethernet (PoE) density. It is the ideal core or distribution switch for modern, bandwidth-intensive deployments, including next-generation Wi-Fi networks, high-resolution surveillance, and sophisticated Pro A/V systems.

Key Hardware Specifications:

• 24 Multi-Gigabit Ports: Includes (22) 2.5 GbE RJ45 ports and (2) 10 GbE RJ45 ports.

• High-Power PoE: All 24 ports support PoE++ (802.3bt Type 3), delivering up to 64W per port with a substantial 600W total PoE budget.

• Fiber Uplinks: Features (4) 10G SFP+ ports for high-speed fiber aggregation to a core network or server.

• Performance: Boasts a 230 Gbps switching capacity and 115 Gbps non-blocking throughput.

Advanced Management and Features: This Layer 3 switch offers advanced features like Static Routing, Inter-VLAN Routing, and DHCP Server/Relay. It supports specialized Pro A/V Profiles (Dante, NDI, etc.) for simplified setup. The integrated Etherlighting™ feature provides intuitive, color-coded port illumination for quick status and network identification. For enhanced reliability, the switch includes a 1.3" touchscreen LCM display for real-time status and is DC Power Backup Ready (compatible with USP RPS).

The USW-Pro-HD-24-PoE is a 1U rack-mountable solution engineered for silent, high-performance operation in enterprise and critical infrastructure settings.
